Name: 1/4HP 3.5 CFM Single Stage Vacuum Pump and R134 R12 R22 Manifold Gauge Set
SKU: 38560769

Manifold Gauge:
Features:
1. Heavy duty hook for hanging the manifold gauge in place.
2. No-flutter gauge design.
3. Solid connections.
4. 60" Color coded charging hose.
5. Ideal for R134, R12, R22.
6. Quick disconnect couplers for high/low fittings included.
Technical Specifications:
1. Operating Pressure: 600 PSI
2. Burst Pressure: 3000 PSI
3. Hose Connectors: 1/4" SAE
4. Gauge Reading: R134 R12 R22
5. Hose Length: 5FT
6. Blue Gauge (Low): 2-1/2" Diameter, 0-220 PSI with 0-30 VAC
7. Red Gauge (High): 2-1/2" diameter, 0-500 PSI
8. Color Coded Charging Hose: 60"
9. Red Hose: 1/4" FFL x 60" with Knurled Fittings
10. Blue Hose: 1/4" FFL x 60" with Knurled Fittings
11. Yellow Hose:1/4" ACME x 60" with Knurled Fittings
12. Dimensions: (14.17 x 4.33 x 13.39)" / (36 x 11 x 34)cm (L x W x H)
13. Material: Plastic &amp; Metal
14. Color: Red &amp; Green &amp; Blue
15. Weight: 2.9kg / 6.39lb
Vacuum Pump
Features:
1. Easy To See Oil Level Window - Oil viewing windows allows you to monitor oil quality and levels.
2. Easy To Maintain: Oil drain plug located at bottom of oil reservoir.
3. Easy To Operate: On/off switch.
4. Turn On &amp; Go: Easy start &amp; maintenance free.
5. Efficient Cooling: Built-in high volume cooling fan for extended use.
6. Portability: Non slip contoured carrying handle
7. Safety: Exhaust port with cap.
Technical Specifications:
1. Free Air Displacement: 3.5 CFM
2. Microns Rating: 37.5 microns (5pa)
3. Power: 1/4HP
4. Pump Speed: 1720 RPM
5. Voltage: 110V @ 60Hz
6. Inlet Port: 1/4" Flare
7. Oil Capacity: 330mL
8. Color: Blue
9. Dimensions: (14.57 x 10.63 x 6.69)" / (37 x 27 x 17)cm (L x W x H)
10. Material: Copper &amp; Aluminum&amp; Plastic
Package Contents:
Manifold Gauge:
1 x Set of R134 R12 R22 Dual Manifold Gauge Set
1 x 134A Adaptor Female 5/16" to Male 1/4"
1 x 410a Adaptor Female and Male 1/4"
Vaccum Pump:
Package Includes:
1 x 1/4 HP 3.5 CFM Horsepower Vacuum Pump
1 x Bottles of Oil&nbsp;
